Mobilephone Bluetooth RFID Reader Access Control products

Mobilephone Bluetooth RFID Reader Access Control products


Specification

1.Working voltage:9~12VDC.
 Current: average 50mA, peak 100mA

 Frequency: 125KHZ-13.56 MHz

 Communication interface: Wiegand26, Wiegand34,RS232

 Environment: temperature -20ºC~65ºC, humidity 0 ~ 95%

 Reading distance: RFID Card: 1~5cm;

 Connection cable: 8pin shielded twisted pair, max 100 m. 8.Size:86*86*18mm.

 Housing material: ABS



Model NameCard Reader Access Control
ColorBlack / White
VoltageDC9~16V
Current≤100mA
Ambient Temperature-25°C~75°C
Reading Range5~15CM
Output FormatWiegang26 or 34,RS232
Card TypeEM-ID/S50,S70,MF
Comunication DistanceWG≤100M


Installation

Using "+"type screw driver to loosen the screw between the panel and motherboard. And then embed the motherboard to the side wall with the plastic plug and screws.

Wire Connection
Red DC 5V-16V
Black GND
Blue D1
White D0
Brown BEEP
Green LED
Yellow Alarm

Notice!
1. Confirm the electric voltage (DC12V) and differentiate positive anode and cathode of power supply
2. When external Power is used, make sure sharing the power with Controller Box or using the same GND
3. When the distance between card reader and controller is more than 50m, please use Power Line with at least 1.5 square cm Dia, or using several parallel Network wires.
