Term:
FOB CIF
Port:
Ningbo, Shanghai
Min. Order:
50 Pieces
Delivery:
30 days after confirmation
Supply Ability:
50000 Piece/Pieces per Month
Payment:
30% Deposit by T/T and the balance before shipment or against the copy B/L
Shipping:
EMS, FedEx, DHL, UPS, By Air & By Sea
Product Parameter | Parameter Description |
Dimensions Option | 70*22*14mm
|
Input | DC12V |
Contact Rating | 12-28V,3A |
Output Contact | NO/NC/COM |
Mechanical Life | 500000 tested |
Suitable for Door | Hollow Door |
Operating temp | -20℃~+55℃(14-131F) |
Suitable Humidity | 0-95% (relative humidity) |
Detection range | 0.1-10cm |
Weight | 0.15kg |
access control exit button Advantage:
. No touch / Touch free Exit Sensor (Diffused Detection)
· Optical / Infrared Technology
· IP-55 Ingress Protection / SUS 304 Stainless steel Plate
· User friendly (Healthy protection)
·· Free from contagious diseases spread
·· Detection range: 0.1 ~ 10 cm
· Application: Gate/Door/Exit/Automation control
·· High capacity of relay dry contact (3A/AC120V,DC30V)
· Normally open/Normally close/Common relay output
· Twin led indicators for sensor standby or approached :
(1) Sensor Standby: BLUE LED ON
(2) Visitors whom approached to the sensor in 10 cm : RED LED ON
