Specifications |
AI07 is widely used as attendance and access control equipment in government agencies, intelligent building buildings, office buildings, high-end real estate communities, colleges and universities, enterprises and institutions, industrial and mining enterprises, etc. |
Product name | AI07 WDR AI Face Recognition&Fingerprint Time Attendance and Access Control Terminal |
Screen | 5.0 Inch IPS Touch Screen, HD 720*1280 |
Keypad | Touch keypad |
Operation system | LINUX 3.10 |
CPU,NPU | 1.2G Dual-Core ARM Cortex-A7, 600G (0.6T) |
RAM | 256MB DDR3 |
ROM | eMMC Flash 4GB |
Binocular camera | Real Sensor 1/2.9 inch FOV 75° 200W pixel high-definition color camera WDR wide dynamic
Sensor 1/5 inch FOV 75°200W pixel infrared live camera |
Live detection | Dynamic dual-camera anti-counterfeiting, to prevent all kinds of black-and-white, color photos and videos from deception |
Fingerprint Sensor | Capacitive |
Logs capacity | 500000 |
Face Registration | Local operation: Enroll face with machine, import user photo with U disk |
Software operation: Import user photo to software, capture user photo with camera |
Verification | Dynamic face recognition, Fingerprint, password, ID/IC card optional |
Face/Fingerprint capacity | 5000 (50000 optional) |
Card Capacity | 5000 (50000 optional), ID Card Standard, IC Card Optional |
Password Capacity | 5000 (50000 optional) |
Face Recognition Accuracy | 99.70% |
Recognition Speed | ≤0.2s, support single user/multi user(at most 5 users) recognition at same time |
Recognition Distance | 0.5~2.5 meters (0.5~1.5 meters with live face recognition on) |
Prevent Photo | Dual camera anti-counterfeiting, prevent recognition with photo/video |
Principle of Identification | Face algorithm technology of multi-task cascaded convolutional neural network based on |
video stream for dynamic face detection, tracking and recognition |
WDR | Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight
Supports simultaneous recognition of up to 5 people, face tracking, face capture |
USB | USB2.0x1，Support U disk import/export data |
Power supply | DC12V interface x 1 |
Speaker Interface | Reserved for extended Speaker Interface |
Network Communication | TCP/IP, Support C/S LAN communication, Wifi (optional) |
Free Attendance sofware | Support exporting excel attendance report with U disk |
Shift | Support shift setting and importing shift schedule with U disk |
Management Software | Desktop, Cloud ,SDK, Mobile APP |
Access Control Function | Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals, anti passback,
interlock |
one set of alarm signals, time permission control, connect external access control reader, |
Group combination to open the door, user effective date |
Wiegand 26/34 output/iutput |
Support lock screen, after locking screen, user have to touch the screen to active the machine, then do face recognition. If not
touch the screen, even if the user stand in front of machine it not recognize face. |
Environmental adaptability | Working temperature: -15C~+45°C (storage temperature -40C~+65°C)， |
Working humidity: 20% ~90% (storage humidity 20%~90+2%)， |
Dark enviroment: LEDSoft light automatic fll light (Automatic control according to ambient light) |
Ambient light adaptation range: 0-50000Lux |
Muti language | Support 20 national languages and voices including English, Spanish, Arabic, Thai, Farsi, Portuguese, French, Italian, Japanese,
Korean, etc
Support Chinese, English, Korean, Persian T9 input method |
Broadcase and ring | Support display name, voice broadcase name, builtin bell ring |
Automatic fill light | Support infrared fill light, the white fll light automatically lights up when face is captured in dark light |
Working Current | stand-by current: 310mA , Working current: 520mA |
Support TTS | Chinese and English voice report name |
QR Code Scanner | Support,Cooperate with cloud platform to realize visitor function |
Working Voltage | DC12V |
Installation Way | Standard: Wall mount, desktop stand; Optional: bracket for turnstile, floor stand |
