TF-12 is a simple standalone fingerprint access control terminal, combined with other access control terminal, easy replace and install for middle and small enterprise.
1. Both use as fingerprint reader and standalone fingerprint access control.
2.Multiple identification: fingerprint,password and card together.
3.500 dip hidden fingerprint sensor for dry fingerprint and strong sunshine.
4.Wiegand out to combine with access controller.
5.Easy operation for register and delete with software management.
6.USB pen driver to download and upload the database to share with other models.
User Capacity | 1000 |
Fingerprint | 500 |
Card | 500 |
PIN | 500 |
Operating Voltage | 12V DC |
Idle Current | <50Ma |
Active Current | < 100 Ma |
Fingerprint Reader | Optical fingerprint Module |
Resolution | 500 DPI |
ldentification time | < 1S |
FAR | < 0.0001% |
FRR | < 0.01% |
Proximity Card Reader | Industry Standard 26 bit |
Radio Technology | 125KHz Industry Proximity EM Card |
Read Range | 1~5cm |
PIN Reader | 4 ~ 6 digits PIN |
Wiring Connections | Relay output, exit button,alarm,Wiegand output |
Communication | Door bell |
Relay | USB for downloading/uploading |
Adjustable Relay Output Time | One (NO, NC, Common) |
Lock Output Load | 1 ~ 99 Seconds (5 seconds default) |
Alarm Output Load | 2 Amp Maximum |
Wiegand Interface | 5 Amp Maximum |
Environment | Wiegand 26 bits output |
Operating Temperature | -20℃ ~ 50℃(50℉~140℉) |
Operating Humidity | 20%RH ~ 90%RH |
Physical | ABS Enclosure |
Dimensions | 8.8L X 8.8W x 3.0H (cm) |
Unit Weight | 350g |
Shipping Weight | 400g |
