1.Completely independent access control, can directly implement user passwords, card management and other functions
2.Fingerprint keyboard input, support card, card plus password to open the door in four
3.Fingerprint&ID standalone access control, using finger V10.0 algorithm, low false positives;
4.Infared fingerprint reader, without sunlight affected;
5.Simple access control function, unlock, go out switch;
6.Supports a password and fingerprint to open the door, fingerprint and stand-alone card capacity up to 1000
7.No Network-based access control, do not keep records;
8.External wired doorbell, comes doorbell button.
1.3000 fingerprint, 1000 card and 1000 password
2.3 access modes: fingerprint, card, PIN
3.Card type: 125KHz EM card
4.PIN length: 4~6 digits
5.Standalone or pass-trough operation
6.Door bell
Product Parameter | Parameter Description |
ID Card Capacity | 1000 |
Fingerprint Capacity | 3000 |
Communication | Wiegand26/34 |
Access Control Interface | 3rd party electric lock, door sensor, exit button, alarm, Door Bell |
Wiegand Signal | Input & Output |
Optional Functions | 125Khz |
Display | N/A |
Power Supply | 12V DC |
Operating Temperature | 0°C- 45°C |
Algorithm Version | Finger V 10.0 |
Dimension(W*H*D)mm | 140*99*26mm(Length×Width×Thickness) |
Fingerprint collector dark background anti - glare anti - fingerprint residual optics,
Standard with U disk function,
Administrator function support 1000 groups of administrators.
Read the card module with 125KHZ RFID.
Wiegand WG26 output,can be use as a wg26 reader
identification speed <1 second,
prompt sound buzzer.
Timeout forced open the door, opened the door,
using temperature 25 ℃ ~ 45 ℃
Power supply +12V,
Operation temperature:-25~45 Degree
